현재 동일한 디자인의 제품은 단종되었습니다.
추후 변경 디자인 올려놓겠습니다.
| Electrical Properties |
|
|
|
|
| Frequency Range |
869~960 MHZ |
|
|
|
| VSWR |
|
< 2.0 |
|
|
|
| Return Loss |
|
> - 11 db |
|
|
|
| Gain |
|
5 dBi |
|
|
|
| Polarization |
|
Vertical |
|
|
|
| Max. Power |
|
100 W |
|
|
|
| Vertical Beam-with |
65 deg |
|
|
|
| Horizontal Beam-with |
360 deg |
|
|
|
| Impedance |
|
50 ohm |
|
|
|
| connector |
|
N Female |
|
|
|
| ● Mechanical Properties |
|
|
|
| Length |
|
600 mm |
|
|
|
| Diameter |
|
18.5mm |
|
|
|
| Weight |
|
450 g |
|
|
|
| Wind Survival |
|
> 150 MPH |
|
|
|
| Radome Material |
White Fiberglass |
|
|
| Operating Temp. |
-40 deg C ~ +80 deg C |
|
|
| Clamps |
|
U-bolt |
|
|
|
| Mounting |
|
32 - 45 mm |
|
|
|
| RoHS Compliant |
yes |
|
