Mechanical specifications
Model	KMS65VP15-045
Frequency Range-MHz	450-470
Bandwidth-MHz	20
Gain-dBi	14.1
Vertical Beamwidth-°	15
Horizontal Beamwidth-°	65
F/B Ratio-dB	≥20
VSWR	≤1.5
Impedance-Ω	50
Polarization	Vertical
Maximum Power-W	500
Lightning Protection	DC Grounded
Connector	N Female
Dimensions-mm	2060×490×110
Weight-Kg	11
Mounting Mast Diameter-mm	Ф40 to 90
