2.3~2.7GHz듀얼섹터15dB
 글쓴이 : 최고관리자
조회 : 1,392

Freq. Range   2300-2700MHz
Gain                  2x15dBi
Polarization        V and H
Horizontal Beamwidth 120º
Vertical Beamwidth      9º
Cross-pol-isolation     >25dB
VSWR          <1.5Type; Max 2.0
Impedance                50 Ω
Lightning Protection  DC Ground
Max. Power             200W
Connector             2-RP SMA
Dimension         700x140x50mm
Weight                       3 kg
Rated Wind Velocity   60 m/s
Mounting Mast Diameter Φ30-70mm
Working Temperature -40℃- +60℃
