Freq. Range    4900-5850 MHz
Bandwidth       950 MHz
Gain                2x16dBi
Horizontal Beamwidth    120°
Vertical Beamwidth          7°
F/B Ratio         >15dB
Isolation           >25dB
VSWR            <1.5Typel; Max 2.0
Nominal Impedance    50Ω
Polarization        Vertical and Horizontal
Max. Power      100 W
Dimension         430x138x45 mm
Weight               2Kg
Rated Wind Velocity   60 m/s
Connector Type          N Female
Dia. Of Pole               Φ30-50
