| Applications |
* 2.4GHz/5GHz WiFi system
* IEEE802.11a/b/g
* Point to multipoint application | |
| |
| Specifications |
| Model |
|
| Frequency Range-MHz |
2400-2483 |
5150-5350 |
5350-5850 |
| Gain-dBi |
5 |
5 |
6 |
| Vertical Beamwidth-° |
30 |
30 |
25 |
| VSWR |
≤2 |
| Impedance-Ω |
50 |
| Polarization |
Vertical |
| Maximum Power-W |
20 |
| Connector |
N female |
| Dimensions-mm |
Φ25×510 |
| Weight-Kg |
0.32 |
| Mounting Mast Diameter-mm |
Φ40 to Φ50 | |
|
