| Applications |
* CDMA800 /3G/WLAN
* 698 to 960/1700 to 2700MHz band
* Indoor coverage system
| |
| Features |
* Broad band, Cover 700 to 2700MHz common system
* Light weight, Small size
* UV stable ABS radome
| | |
|
Specifications |
| Model |
|
| Freq.Range-MHz |
698～960 |
1700～2700 |
| Gain-dBi |
7 |
10 |
| Hor.Beamwidth-° |
70 |
60 |
| Ver.Beamwidth-° |
55 |
45 |
| VSWR |
≤2.0 |
≤1.5 |
| Impedance-Ω |
50 |
| Polarization |
Vertical |
| Max.Power-W |
50 |
| Connector |
N Female or customized |
| Dimension-mm |
210×180×44 |
| Weight-Kg |
0.4 |
| Color |
White |
|
Mounting |
Wall mounting | | |
|
