Specifications |
| Model |
|
| Freq.Range-MHz |
698～960 |
1710～2700 |
| Gain-dBi |
5 |
7 |
| Hor.Beamwidth-° |
95±15 |
75±15 |
| Ver.Beamwidth-° |
100 |
70 |
| VSWR |
698～806/806～960 ≤2.0
1710～2500≤1.5
2500～2700 ≤2.0 |
| Impedance-Ω |
50 |
| Polarization |
Vertical |
| Max.Power-W |
100 |
| Connector |
N Female or customized |
| Dimension-mm |
φ170×72 |
| Weight-Kg |
0.4 |
| Mounting way |
Fixed with Nut |
|
